PTFE Seamless Tabber String Belt

  • PTFE Tabber Stringer Belts with Seamless 2 rows of holes
PTFE Tabber Stringer Belts with Seamless 2 rows of holes

PTFE Tabber Stringer Belts with Seamless 2 rows of holes

  • Brand: WELLFLON
  • Material:PTFE, Fiberglass
  • Features:100% Nonstick, High Temp Resistant
  • Temp Resistance: -70°C to +280°C
  • Product description: PTFE Tabber String Belts are also called as Solar Laminated Belts, which are laminated by two layers of PTFE Coated Fiberglass Fabric.
  • INQUIRY

PTFE Tabber Stringer Belts with Seamless 2 rows of holes

Changwei® stringer belt is made of high-strength glass fiber yarn or Kevlar (aramid) woven fabric with circular weaving equipment, and is made of PTFE resin by a unique process technology. It overcomes the phenomenon that the connection of the conveyor belt interface is easy to break. The circumference of the joint is not equal, resulting in poor stability and deviation. The running life of the seamless belt is more than three times longer than that of any Teflon conveyor belt.

The belt is equipped with advanced instruments to produce the required aperture on the belt according to the customer's needs.

As shown in the figure, the width of the stringer of the two rows of holes is normal: 0.5cm, hole length: 1.2cm


Precautions of PTFE Tabber Stringer Belts with Seamless 2 rows of holes:

With the popularization of conveyor belts in industrial production, many varieties, high performance, light weight, multi-function, long life are several aspects that manufacturers pay attention to. In industrial production, the correct use of conveyor belts is particularly important, the following points should be noted in the use of conveyor belts:

1. Avoid the roller being covered by the material, causing the rotation to be ineffective, preventing the leakage from getting stuck between the roller and the tape, paying attention to the lubrication of the movable part of the conveyor belt, but not the oily conveyor belt;

2. Prevent the conveyor belt from starting;

3. When the conveyor belt runs off, measures should be taken to correct it;

4. When the conveyor belt is partially damaged, the artificial cotton should be repaired in time to avoid expansion;

5. Avoid the belt being blocked by the frame, pillars or block materials to prevent breakage and tearing.


Properties of PTFE Tabber Stringer Belts with Seamless 2 rows of holes:

With one side brown surface, and other side anti-static property, this belt has super Non-stick and Anti-static surface, and long lifetime which is much better than one layer PTFE Belt.

Changwei's Tabber Stringer Belt always run very straight, the dimension is superior stable also, we are supplying to lots of manufacturers of Tabber Stringer Machine and end-clients who using this machine.


Features of PTFE Tabber Stringer Belts with Seamless 2 rows of holes:

1. Anti-static

2. Run very Straight

3. Outstanding Long Lifetime

4. Super Dimension Stability

5. Custom Hole and Belt size

6. Heat-resistant

7. Superior Non-stick


Popular Size of PTFE Tabber String Belts:

200mm*4400mm

200mm*3509mm

200mm*6004mm

Any sizes could be customized.

We have a wide selection at great prices to help you get creative. All the Laminated Belts are quality guaranteed. We are China Origin Factory of Heat Resistant Belts.

If you have any question, please feel free to contact us.


Physical Characteristic of PTFE Tabber Stringer Belts with Seamless 2 rows of holes:

Item No.

Color

Thickness (mm)

Weight of Fiberglass(g/m2)±3%

Total Weight (g/m2) ±5%

Tear Strength (N/5cm) ±5%

Temperature Resistance

Warp

Weft

CWF-0070

black/white/brown

0.065

48 70 500 460 -70 ~+280℃
CWF-0150
black/white/brown
0.07
48 150 650 550 -70 ~+280℃
CWF-0165
black/white/brown
0.08 48 165 700 600 -70 ~+280℃
CWF-0130
black/white/brown
0.095
105 130 820 800 -70 ~+280℃
CWF-0220
black/white/brown
0.105
105 220 900 750 -70 ~+280℃
CWF-0230
black/white/brown
0.115
105 230 1150 1000 -70 ~+280℃
CWF-0250
black/white/brown
0.125
105 250 1200 1100 -70 ~+280℃
CWF-0300
black/white/brown
0.14
105 300 1350 1250 -70 ~+280℃
CWF-0350
black/white/brown
0.17
165 350 1750 1550 -70 ~+280℃
CWF-0360
black/white/brown
0.18
165 360 1800 1650 -70 ~+280℃
CWF-0275 black/white/brown
0.2
205 275 2000 1800 -70 ~+280℃
CWF-0440
black/white/brown
0.22
205 440 2400 1650 -70 ~+280℃
CWF-0490
black/white/brown
0.23
205 490 2200 1750 -70 ~+280℃
CWF-0500
black/white/brown
0.24
205 500 2200 1850 -70 ~+280℃
CWF-0500
black/white/brown
0.25
205 500 2500 2000 -70 ~+280℃
CWF-0620
black/white/brown
0.28
293 620 2500 1800 -70 ~+280℃
CWF-0385
black/white/brown
0.31
283 385 1900 1400 -70 ~+280℃
CWF-0620
black/white/brown
0.32
255 620 3000 2100 -70 ~+280℃
CWF-0690
black/white/brown
0.35
333 690 3200 2200 -70 ~+280℃
CWF-0770
black/white/brown
0.39
333 770 3200 2100 -70 ~+280℃
CWF-0540
black/white/brown
0.43
405 540 3500 2400 -70 ~+280℃
CWF-1000
black/white/brown
0.53
538 1000 4200 3500 -70 ~+280℃
CWF-1180
black/white/brown
0.63 578 1180 4500 3800 -70 ~+280℃
CWF-1550
black/white/brown
0.78 768 1550 5500 4000 -70 ~+280℃
CWF-1600
black/white/brown
0.9 865 1600 6500 5500 -70 ~+280℃
CWF-1250
black/white/brown
0.98 852 1250 6000 5000 -70 ~+280℃
