PTFE Solar Laminating Fabric

  • Solar Laminating Fabric
  • Solar Laminating Fabric
  • Solar Laminating Fabric
  • Solar Laminating Fabric
Solar Laminating FabricSolar Laminating FabricSolar Laminating FabricSolar Laminating Fabric

Solar Laminating Fabric

  • Brand: WELLFLON
  • Materials: PTFE , Fiberglass
  • Features:100% Nonstick, High Temp Resistant
  • Temp Resistance: -70°C to +280°C
  • Product description: PTFE Laminated Fabric for solar cell laminating machine applies high quality glass fabrics combined with specially formulated high level of PTFE content to produce super smooth, high-gloss surface coating.
  • INQUIRY

Solar Laminating Fabric

PTFE Laminated Fabric for solar cell laminating machine applies high quality glass fabrics combined with specially formulated high level of PTFE content to produce super smooth, high-gloss surface coating. In addition to providing the properties of excellent release, abrasion resistance, low friction and chemical resistance, PTFE laminated fabrics are dimensionally stable from -70°C to +260°C. Because of their non-toxic, odorless and tasteless qualities they have been approved for the Application of Solar Panel Laminating.

Properties Of Solar Laminating Fabric:

1. Superior non-stick surface, enables lifetime as a laminator sheet.

2. Excellent dimensional stability and strong tensile strength due to glass fabrics.

3. Outstanding temperature resistance from -170°C to 260°C.

4. Strong resistance to all chemicals, do not worry about the bad effect caused by chemicals during production.

5. Reusable, enables your working efficiency.

We Recommend The Sizes Of Solar Laminating PTFE Fabric:

Normal sizes: 2.2m×3.6m;2.2m×5.4m;1.2m×2.3m

Other sizes can also be made.


We also have PTFE laminated fabric with rough surface on one side which is applied as conveyor belt for the solar cell to go through automatic laminating machine.


PTFE Laminated Fabric(8)




Physical Characteristic Of Solar Laminating Fabric:

Item No.

Color

Thickness (mm)

Weight of Fiberglass(g/m2)±3%

Total Weight (g/m2) ±5%

Tear Strength (N/5cm) ±5%

Temperature Resistance

Warp

Weft

CWF-0070

black/white/brown

0.065

48 70 500 460 -70 ~+280℃
CWF-0150
black/white/brown
0.07
48 150 650 550 -70 ~+280℃
CWF-0165
black/white/brown
0.08 48 165 700 600 -70 ~+280℃
CWF-0130
black/white/brown
0.095
105 130 820 800 -70 ~+280℃
CWF-0220
black/white/brown
0.105
105 220 900 750 -70 ~+280℃
CWF-0230
black/white/brown
0.115
105 230 1150 1000 -70 ~+280℃
CWF-0250
black/white/brown
0.125
105 250 1200 1100 -70 ~+280℃
CWF-0300
black/white/brown
0.14
105 300 1350 1250 -70 ~+280℃
CWF-0350
black/white/brown
0.17
165 350 1750 1550 -70 ~+280℃
CWF-0360
black/white/brown
0.18
165 360 1800 1650 -70 ~+280℃
CWF-0275 black/white/brown
0.2
205 275 2000 1800 -70 ~+280℃
CWF-0440
black/white/brown
0.22
205 440 2400 1650 -70 ~+280℃
CWF-0490
black/white/brown
0.23
205 490 2200 1750 -70 ~+280℃
CWF-0500
black/white/brown
0.24
205 500 2200 1850 -70 ~+280℃
CWF-0500
black/white/brown
0.25
205 500 2500 2000 -70 ~+280℃
CWF-0620
black/white/brown
0.28
293 620 2500 1800 -70 ~+280℃
CWF-0385
black/white/brown
0.31
283 385 1900 1400 -70 ~+280℃
CWF-0620
black/white/brown
0.32
255 620 3000 2100 -70 ~+280℃
CWF-0690
black/white/brown
0.35
333 690 3200 2200 -70 ~+280℃
CWF-0770
black/white/brown
0.39
333 770 3200 2100 -70 ~+280℃
CWF-0540
black/white/brown
0.43
405 540 3500 2400 -70 ~+280℃
CWF-1000
black/white/brown
0.53
538 1000 4200 3500 -70 ~+280℃
CWF-1180
black/white/brown
0.63 578 1180 4500 3800 -70 ~+280℃
CWF-1550
black/white/brown
0.78 768 1550 5500 4000 -70 ~+280℃
CWF-1600
black/white/brown
0.9 865 1600 6500 5500 -70 ~+280℃
CWF-1250
black/white/brown
0.98 852 1250 6000 5000 -70 ~+280℃
